Reer VISION VX User Manual

8540571 - 25/08/2016 - Rev.15 25
RECEIVER SIGNALS VISION VX MASTER or VX (with additional functions)
Normal operation (FIXED SYMBOLS)
7 SEGMENTS DISPLAY
LED
SYMBOL
MEANING
RED (2)
GREEN (3)
YELLOW (1)
8
System power on. Initial TEST
ON
OFF
ON
C
Light-on for 10sec: Manual
with feedback disabled
ON
OFF
OFF
C
Light-on for 10sec: Manual
with feedback enabled
ON
OFF
ON
C
Light-on for 10sec: Automatic
with feedback disabled
OFF
ON
OFF
C
Light-on for 10sec: Automatic
with feedback enabled
OFF
ON
ON
None
BREAK condition (A)
ON
OFF
OFF
None
CLEAR condition (B)
ON
OFF
ON
None
Master in Clear, Slave in BREAK
ON
OFF
Blinking
None
GUARD Condition (C)
OFF
ON
OFF
d
BREAK condition with weak signal
ON
OFF
OFF
d
CLEAR condition with weak signal
ON
OFF
ON
d
Master in CLEAR, Slave in BREAK
condition with weak signal
ON
OFF
Blinking
d
GUARD condition with weak signal
OFF
ON
OFF
-
Receiver initialization
ON
OFF
OFF
(A) Barrier occupied - output disabled
(B) Barrier free - output disabled - Waiting for restart
(C) Barrier free - output enabled
Configuration errors (BLINKING SYMBOLS)
7 SEGMENTS DISPLAY
LED
SYMBOL
MEANING
RED (2)
GREEN (3)
YELLOW (1)
C
Customer configuration rejected
ON
OFF
OFF
2
OSSD erroneously connectedt o 24VDC
ON
OFF
OFF
E
External Feedback contactors missed
ON
OFF
OFF
SLAVE RECEIVER SIGNALS
Normal operation (FIXED SYMBOLS)
7 SEGMENTS DISPLAY
LED
SYMBOL
MEANING
RED (2)
GREEN (3)
YELLOW (1)
8
System power on. Initial TEST
ON
OFF
ON
Nessuno
BREAK condition
ON
OFF
OFF
Nessuno
GUARD Condition
OFF
ON
OFF
d
BREAK condition with weak signal
ON
OFF
OFF
d
GUARD condition with weak signal
OFF
ON
OFF
-
Receiver initialization
ON
OFF
OFF
