Reflex Marine WAVE4 - Product Specifications

Rev 1.0
5
1.2 Product Specifications
Category
Description
Specification
Model No.
WV4
Passenger
Capacity
Standard
4
Stretcher Mode
2 Passengers + Stretcher
Luggage
Capacity
Light Luggage
Central luggage net
Large Luggage
Below central luggage net
Passenger
Safety
Fall Prevention
Passenger safety restraints + hand grips
Metric
Imperial
Operating
Temperatures
Standard Model
-20°C to +50°C
-4°F to 122°F
Impact
Protection
Vertical impacts
Up to 2.14 m/s
Up to 7.0 ft/s
Lateral impacts
Up to 2.0 m/s
Up to 6.6 ft/s
Dimensions
(Nominal)
Width 1
1710 mm
67 in
Width 2
1710 mm
67 in
Height
2336 mm
92 in
Weight
Maximum Gross Mass
850 kg
1874 lbs
Tare Weight
350 kg
772 lbs
Payload
500 kg
1102 lbs
Lifting Points
SWL
Main 1
850 kg
1874 lbs
Main 2
850 kg
1874 lbs
Wire Rope
Lifting
Assembly
Safe Working Load
850 kg
1874 lbs
Wire Rope
2 leg anti-rotation wire rope
Stability
Horizontal
32°, for a load of 1-4 passengers.
Submerged Self-
Righting
Up to 180˚ inverted to the vertical position
Materials
Frame
316 Stainless steel, A4 stainless fixings
Central Columns /
Load Plate
316 Stainless
Floor Grating
GRP
Buoyancy
PE moulded shell with Polyurethane (PU)
closed cell foam fill.
Landing Feet
EVA Foam
VERIFICATION & CERTIFICATION
Certification
Class
EC Attestation of Conformity Certificate No.
MAC000008 i01
ABS Statement of Fact
Quality
System
Manufactured to ISO 9001:2008
Standards
National Technical
Standards
UK, BS EN 1993 series: The design of steel
structures
Industry European
Standards
EC Machinery Directive
BS EN ISO 12100:2010
Load Test – ILO152 / LOLER
National Regulations
UK, PUWER / LOLER
Table 1 - WAVE Specification
