Rega fono mc User Manual

specications /
Input sensitivity (for 200mV output)
4 o = 133uV
4 on = 67uV
Input loading resistance
1 and 2 o = 400Ω
1 on = 100Ω
2 on = 150Ω
1 and 2 on = 70Ω
Input loading capacitance
3 o = 1000pF
3 on = 4300pF
Gain (at 1KHz)
4 o = 63.5dB
4 on = 69.5dB
Maximum input level (at 1KHz)
4 o = 6.7mV
4 on = 3.4mV
Output impedance = 200Ω
Recommended minimum output load resistance = 5K
Frequency response (50KΩ output load) = 13Hz (-3dB) to 100KHz (-0.3dB)
RIAA accuracy (50KΩ output load) = Better than +/-0.2dB 100Hz to 100KHz
Power requirements = 24V AC at 150mA maximum. Only to be used with Rega PS1.
power supply /
Connect the Rega PS1 to the AC socket on the Fono back panel.
8 / 9 /
English

Rega fono mc Specifications

General

Power consumption	5 W
Type	Phono Preamplifier
Output impedance	200Ω
Frequency response	13 Hz (-3 dB) to 100 kHz (-0.3 dB)
Power Supply	24 V AC
