Rega fono mm User Manual

method of connection /
INPUT
Connect the tonearm leads and earth (if used) to the input socket and to the earth
terminal on the back of the Fono.
Turntable Earth
If the turntable or tonearm has a separate signal earth connection this should be
connected to the turntable earth terminal on the back of the unit.
OUTPUT
Connect the output socket of the Fono to the line input on the amplier.
Please note: If you have an integrated amplier with built in phono stage, DO NOT
connect the Fono to this input.
POWER SUPPLY
Connect the Rega PS1 to the AC socket on the Fono back panel.
4 /
English

Rega fono mm Specifications

General

Input Loading	47kΩ in parallel with 100pF
Gain	41.4dB at 1kHz
Output Impedance	100Ω
Recommended Minimum Output Load Impedance	5kΩ
Power Requirements	24V AC
Type	Phono stage
Signal to Noise Ratio	78dB
