Rega fono mm User Manual

specications /
Input sensitivity = 1.7mV for 200mV
output
Input loading = 47KΩ in parallel with
100pF
Maximum input level = 60mV at 1KHz
Gain = 41.4dB at 1KHz
Output impedance = 200Ω
Recommended minimum output load
resistance = 5KΩ
Frequency response (50KΩ output load) =
15Hz (-3dB) to 100KHz (-0.2dB)
RIAA accuracy (50KΩ output load) =
better than +/-0.2dB 100Hz to 100KHz
Power requirements = 24V AC at 80mA
maximum. Only to be used with Rega PS1.
PS1 (UK) Input...................................................230V ~ 50Hz 0.07A Output......................................................24V ~ 350MA AC PS1 (EU - Euro 2 pin) Input...................................................230V ~ 50Hz 0.07A Output......................................................24V ~ 350MA AC PS1 (UL - American) Input..........................................................115-120V ~ 60Hz Output......................................................24V ~ 350MA AC The Rega PS1 and Fono MM amplier is a class II apparatus.
Use only with the Rega PS1 power
supply. Never expose the unit to
rain or moisture. Do not open the
case covers. There are no user
serviceable parts inside.
6 /
English

Rega fono mm Specifications

General

Input Loading	47kΩ in parallel with 100pF
Gain	41.4dB at 1kHz
Output Impedance	100Ω
Recommended Minimum Output Load Impedance	5kΩ
Power Requirements	24V AC
Type	Phono stage
Signal to Noise Ratio	78dB
