Rega Osiris User Manual

Power output
Power output
Input sensitivity for 160 Watts into 8
Line input 1
Line inputs 2-5 and record
Direct input
Amplifier gain: Direct input
Record output (with rated input level)
Frequency Response referenced to
160 Watts into 8 (all inputs)
THD + Noise
Power consumption at 160 Watts per channel into 8
Remote control
Dimensions H x W x D cm
Mains Fuse 230v version
Mains Fuse 115v version
Osiris system remote batteries
Weight
162 Watts per channel into 8 (Rated power output)
250 Watts per channel into 4 (max-power output)
250mV load 10K (transformer balanced)
220mV load 22K
220mV Load 50K
44dB
215mV into 100K
10Hz (-1.7dB point) to 75KHz (-3dB point)
20Hz to 26KHz (-0.5dB points)
Less than 0.05% (Bandwidth 22Hz to 30KHz
560W at 115/230V
Phillips RC5 system number 16 audio pre amplifier
12.2 x 43.4 x 35
3.15A
6.3A
AAA (1.5) x 2 (Supplied)
25.6 kg
TECHNICAL SPECIFICATIONS
9
WARNING
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
To avoid electrical shock, do not attempt to open the case.
Refer servicing to qualified Rega agents only.

Rega Osiris Specifications

General

Type	Integrated amplifier
Total Harmonic Distortion	< 0.05%
Headphone Output	Yes
Outputs	1 x Preamp output
Signal to Noise Ratio	> 100 dB
Power Output	162 W per channel into 8 Ω
Inputs	4 x Line Level (RCA), 1 x Direct input
Dimensions	432 x 360 x 120mm (W x D x H)
