Regada SP 1 User Manual

SP 1, SP 2, SP 2.3, SP 2.4 11
SPR1, SPR 2, SPR 2.3, SPR 2.4
Capacitive transmitter linearity error..................................................................................................... ±1,2[%]
1)
Capacitive transmitter hysteresis....................................................................................................max. 0,6 [%]
1)
Electronic positional transmitter (EPV) - converter R/I (B3)
a) 2-wire version - without built-in power supply, or with built-in power supply
Current signal ....................................................................................................................... 4 ÷ 20 mA (DC)
Power supply voltage ...............................................................................................................15 ÷ 30 V DC
Power supply voltage (at version with build-in power supply) .................................................24 V DC ±1,5%
Load resistance (at version without build-in power supply)....................................max. R
L
=(Un-9V)/0,02A [Ω]
(Un - power supply voltage [V])
Load resistance (at version with build-in power supply).........................................................max. R
L
= 750 Ω
Temperature dependency.......................................................................................... max. 0,020 mA / 10 °C
Output signal values at limit positions: .........................................................."O“..... 20 mA (terminals 81,82)
..............................................................."Z“........ 4 mA (terminals 81,82)
Values tolerance of output signal of EPV............................................................................."Z“....... +0,2 mA
....................................................................................."O“....... ±0,1 mA
b) 3-wire version - without built-in power supply, or with built-in power supply
Current signal ....................................................................................................................... 0 ÷ 20 mA (DC)
Current signal ....................................................................................................................... 4 ÷ 20 mA (DC)
Current signal ......................................................................................................................... 0 ÷ 5 mA (DC)
Power supply voltage (at version without built-in power supply) ............................................ 24 V DC ±1,5%
Load resistance ............................................................................................................................ max. 3 kΩ
Temperature dependency.......................................................................................... max. 0,020 mA / 10 °C
Output signal values at limit positions: .............................................. "O“.... 20 mA or 5 mA (terminals 81,82)
.................................................... "Z“...... 0 mA or 4 mA (terminals 81,82)
Values tolerance of output signal of EPV transmitter ................................................................... "Z“ +0,2 mA
............................................................................................................................................. "O“ ±0,1 mA
EPV linearity error:........................................................................................................................... ±1.5 %
1)
EPV hysteresis:.......................................................................................................................... max. 1.5 %
1)
1)
from rated value of transmitter referred to output values
Electronic position controller (N)
Controller software equipment:
A) Function and parameters
programmable functions:
•...with functional buttons SW1, SW2 and LED diodes D3, D4 directly placed on controller
•...with computer or terminal equipped with corresponding programme, using RS 232 interface.
programmable parameters:
•...control signal
•...response to SYS-TEST signal
•...mirroring (ascending/descending characteristics)
•...insensitiveness
•...EA limit positions (only with computer and ZP2 programme)
•...way of regulation
B) Operation states of controller
Error message from error memory: (using LED diodes and RS 232 and personal computer)
•...control signal missing or faulty
•... input value of current control signal under 3.5 mA
•...existence of SYS-TEST signal
•...activity of switches
•...failure of feedback position transmitter
Statistic data: (using RS 232 and personal computer)
•...number of controller operation hours
•...frequency of relay switching in direction "opening"
•...frequency of relay switching in direction "closing"
Supply voltage: ............................................................................... terminal 61 (L1) -1(N) - 230 V AC ±10%
Frequency: .............................................................................................................................. 50/60 Hz ±2%
