24 SP 1, SP 2, SP 2.3, SP 2.4
SPR1, SPR 2, SPR 2.3, SPR 2.4
5.2 Maintenance - extent and periodicity
During inspections and maintenance is needed to tighten all screws and nuts that affect the tightness and
coverage. Similarly, once a year should be checked and if necessary tighten mounting screws of the terminal
wires and assuring of the slip-on joints with wires.
The interval between two preventive inspections is four years.
The replacement of cover gaskets and gasket of an oil filling is needed in case of damage or after 6 years of the
operation.
The grease in the supplied actuators is designed for the lifetime of the product.
It is not necessary to change the grease during the operation of the actuator.
Lubrication:
• - gear part - in versions for climate with temperatures -25°C till +55°C – grease HF 401/0 (GLEIT-µ) resp.
GLEITMO 585 K
- in versions for climate with temperatures -50°C till +40°C grease ISOFLEX TOPAS AK 50.
Lubrication of the valve stem is independent on maintenance of the EA!
After every potential flooding of the product check, whether there is no water inside. After eventual water
penetration, dry the product before repeated putting into operation and replace damaged sealings, resp. other
parts of EA. identically check also tightness of cable bushings and replace them, if they are damaged.
• Every six months it is recommended to perform one check move in frame of adjusted operation stroke to verify
reliability of functioning with setting back to the original position.
• If the audit rules do not determine else the inspection of EA is performed ones a year and tightening of all
connecting and grounded screws have to be checked to avoid overheating.
• After 6 months from putting of EA into operation and once a year it is recommended to check tightening of
fixing screws between the EA and the valve. (Tighten the screws with the cross system.)
• While connecting and disconnecting of the EA check the tightness of cable glands – those with
damaged sealings should be replaced by new ones of the approved type!
• Keep the EA clean and take care about removing impurities and dust. The cleaning has to be
performed regularly according to the operation possibilities and requirements.
5.3 Troubleshooting
At failure of power supply the EA stops in the position where it was before the failure. If needed the EA
can be set only with the manual control (the handwheel). After restoration of power the EA is prepared for
operation.
In case of failure of any element of the EA it can be changed by a new one. Entrust the change to a
service centre.
In case of an EA failure, which cannot be eliminated directly in operation, follow instructions for under-
guaranty and after-guaranty service.
For controller repair a F1,6 A subminiature fuse for PCB should be used, alternativelly also F 2A, 250 V e.g. Siba
type 164 050.1,6 or MSF 250, and for DB .... voltage source repair a M160 mA, 250V fuse, e.g. Siba, or MSF
250.
Note:
If the EA requires dismantling follow the chapter "Dismantling".
Taking the EA to pieces for repair purposes is allowed only by professionally qualified persons trained
in the production plant or by a contracted service centre!
!
