Chapter 7
TYPICAL MERCRUISER ALPHA PROPELLER INSTALLATION
Follow the steps below to install a propeller on a MerCruiser
equipped propulsion package:
1. Coat the propeller sha with the recommended marine lubricant.
2. Place the forward thrust hub on the prop sha with the taper
matching the taper on the propeller sha .
3. Slide drive hub on next install the propeller.
4. Place the drive sleeve adapter in place.
5. Place the tab washer on the sha .
6. Install locknut to manufacturer speci cations with a torque
wrench.
1) Forward rust Hub
2) Flo-Torque Drive Hub
3) Propeller
4) Drive Sleeve Adapter
5) Tab Washer
6) Locknut
Typical MerCruiser Alpha Drive Installation
