Technical Information
12-9
TRAILER CONNECTOR PLUG INSERTS
INTO BOAT BOW RECEPTACLE
1
2
3
4
16 GAUGE GREEN
16 GAUGE YELLOW
16 GAUGE BROWN
16 GAUGE WHITE
TRAILER HARNESS
16 GAUGE BLACK
16 GAUGE GREEN
16 GAUGE YELLOW/BLACK
TRAILER
CONNECTOR
PLUG
BOAT BOW
RECEPTACLE
TYPICAL TRAILER PLUG
