REFERENCE ONLY
NOTES:
1. HARNESS TO BE INSTALLED AS SHOWN.
2. HARNESS TO BE SECURED EVERY 18" MIN.
3. INSTALL CHAFE PROTECTION AS NEEDED.
REVISION:DATE:
DRAWN BY:
DWG. NO.:
02/21/14
Mike B
-
ALL RIGHTS RESERVED
2300 JETPORT DRIVE
ORLANDO, FLORIDA 32809
TEL (407) 851-4360
REGAL MARINE INDUSTRIES
1 OF 1
PROPRIETARY AND CONFIDENTIAL:
THE INFORMATION CONTAINED IN THIS DRAW ING IS THE SOLE PROPERTY OF REGAL MARINE
INDUSTRIES. ANY REPRODUCTION IN PART OR AS WHOLE WITHOUT THE WRITTEN
PERMISSION OF REGAL MARINE INDUSTRIES IS PROHIBITED.
PAGE:
APPROVED BY:
DRAWING TITLE:
EFP22B
2000 (FP) Deck to Sump Harness
JAH
BILGE
PUMP
FUEL
LEVEL
SENDER
HALON
CE OPTION ONLY
DECK
HARNESS
CONNECTOR
BILGE
BLOWER
Battery Switch
Arch Actuator box
MAIN NEG
GROUND BUSS
To Next Page
