16
Chapter 7
SEAT-HELM
The helm seat features an electric hydraulic mechanism
which moves the captiain’s seat fore-aft and up-down to
accommodate different body types and cruising options.
In addition, the companion seat moves fore and aft.
Both seats feature a leaning post to gain extra height or
additional standing room at the helm when maneuvering
in close quarters.
There is a dual set of toggle style switches labeled captain’s
seat to the starboard side of the helm. Press the left switch
to control the fore and aft movement. The right switch
controls the seat’s up and down movement.
The companion seat (labeled Comp. Seat) switch is on the
helm being part of a 4 switch panel. This switch controls
the seat’s fore and aft movement.
To add seat height using the leaning bolster lift the front
of the helm seat and pull the leaning bolster upward until
fully extended. See the illustration.
Helm Seat-
Stand Up
Use Or Increase
Seat Height
Helm Seat
Switches
CAPTAIN’S SEAT SWITCHES
