53
Auxiliary Equipment Operation
To use the chaise lounge portion of the sunpad, pull up
on the framework from a side position. Then pull the
adjuster-receiver arm to stern which will lock it at the de-
sired angle. Ensure that the arm is secured in the deck-
track.See the illustration.
Place Adjuster-Receiver
Arm In Track
SUNPAD FRAMEWORK-SIDE VIEW
SUNPAD FRAMEWORK-FRONT VIEW
TYPICAL SUNPAD FRAMEWORK
Adjust Angle-Pull Up On Framework
Adjuster-Receiver Arm
To Next Page
