27
Systems
ENGINE IGNITION SWITCH
As designated by the illustration dual ignition switches are
used to crank over and start the diesel engines. The left
ignition switch controls the port engine and the right igni-
tion switch controls the starboard engine.
Each ignition switch features 3 positions.
STOP- SPRING LOADED TO THE LEFT.
ON- SUPPLIES IGNITION POWER TO ENGINE.
START- SPRING LOADED TO THE RIGHT.
Each ignition switch features 3 positions.
Refer to the engine chapter for further information.
AVOID POSSIBLE BODILY INJURY OR DEATH!
REMOVE KEYS FROM THE IGNITION
SWITCHES WHEN THE ENGINES
ARE NOT RUNNING.
