Regency Alterra - Side Panel Installation; Fan Installation; Fan Wiring Diagram

Regency Alterra Freestanding Wood Fire
7
installation
SIDE PANEL INSTALLATION
FAN INSTALLATION
F
H
A 2 speed fan is supplied and needs to be fitted to the rear of the unit
with screws supplied.
Install side panels with screws as shown in diagram.
Diagram 1 - Side Panel Install
Diagram 1 - Fan Install
Diagram 2 - Fan Wiring Diagram
