Regency Alterra Freestanding Wood Fire
installation
MINIMUM CLEARANCE TO
COMBUSTIBLE MATERIALS
Universal
Default (1)
AHD
Special (2)
A
*B
C
D
E
G
H
Floor Protection
the heater as follows;
which has a thermal resistance of 0.8m
2
k/w for 4mm sheets of cement
The ue pipe shall extend not less than 4.6m above the top of the oor protector.
NOTE: Installation must be carried out by a licensed installer in accordance
with AS/NZS 2918:2001.
IMPORTANT
* (1) The Universal Default flue kit requires one 130
o
x 900mm
stainless reflective shield; fitted to the rear of the active flue.
* (2) The AHD Special Insulated flue kit must be installed with a
40mm air gap around the flue to any combustible surfaces and the
ceiling ring must be spaced as such to provide an air gap of 20mm
to the ceiling.
A 130º x 900mm stainless reflective must be fitted behind the active
flue.
* Wall clearance taken from rear shield (not fan).
NOTE: A minimum clearance of 160mm (flat wall) or 175mm (corner wall) must be retained for all wall surfaces to allow for fan access and maintenance.
