L390E / HZI390E Direct Vent Gas Insert
35
INSTALLATION
4 SIDED LOW PROFILE FACEPLATE INSTALLATION
2) Install front faceplate and secure to the unit with 4 screws in locations
shown below.
Final Install
Note: Faceplate may be installed after the unit is in it's fi nal position.
1) Install Low Profi le faceplate backing plate and secure to the unit with 4
screws in locations shown below.
To Next Page
