L390E / HZI390E Direct Vent Gas Insert
47
PARTS LIST
MAIN ASSEMBLY
Part # Description
1 396-035 Door Frame
2 936-159 Window Gasket
3 396-112 Window Gasket Retainer
4 396-045 Burner Mounting Bracket Right
5 396-111 Burner End Right
6 396-023 Control Cover
7 911-078 Pilot Assembly NG Sit
911-079 Pilot Assembly LP Sit
8 396-111 Burner End Right
9 396-010 Exhaust Baffl e
10 396-101 Light Cover
11 396-024 Slide Reinforcement
12 396-042 Slide Tool
13 396-514 Flue Connector Plate Assy
14 396-018 Flue Connector Plate Gasket
15 393-030 Bulkhead Clamp
16 396-029 Bulkhead Clamp Gasket
17 904-658 Gas supply line
18 904-165 Connector 3/8"MPT - 3/8"Flare
19 396-028 Valve Mounting Bracket - R
20 911-084 Valve NG 885
911-085 Valve LP 885
22 396-023 Control Cover
24 904-944 90° elbow 3/8"MPT-3/8"Flare
25 396-034 Valve mounting bracket - L
26 911-074 Ignition board SIT IPI
27 910-572 SIT Profl ame receiver
28 911-074 Pilot Assy Ground Wire
29 396-043 Firebox Liner Retainers
30 396-114 Burner End - L
Part # Description
31 904-943 Orifi ce mount
32 Air Shutter Assy
396-032 Air Shutter
396-033 Burner Mounting Bracket
396-116 Orifi ce Mounting Gasket
34 396-513 Bottom Door Latch Assy
35 904-946 NG orifi ce #37
904-947 LP orifi ce #53
36 396-125 Pilot Shield
37 396-046 Burner Mounting Bracket - L
38 396-113 Pilot Line Cover
39 904-691 Glass Clip Retainer
40 396-039 Door Tool
46 911-013 Profl ame Wire Harness
49 396-969 LP Conversion Kit
50 396-930 Ceramic Log Kit (6 pc)
51 396-530 Ceramic Burner
52 396-901 Brick Panels - Brown
396-902 Brick Panels - Rec
53 396-908 Enamel Panels
54 396-525 Glass Burner Assy
56 396-917 Fan Kit Manual
58 N/A Light Kit
61 Various Glass Crystals
62 396-094 Glass Tray
63 396-091 Pilot Cover
64 396-122 Burner Screen
65 904-790 Magnets
66 918-982 Manual
* Not Shown
* 911-071/P Fan Motor Only
* 910-142 Fan Thermodisc
* 911-030 Fan Control Module
To Next Page
