Optigo OP10
Technical data
Supply voltage OP10: 24 V AC ±15 %, 50...60 Hz
OP10-230: 230 V AC +10 %, -15 %, 50...60 Hz
Internal consumption 4 VA
Ambient temperature 0...50°C
Storage temperature -20...70°C
Ambient humidity Max. 95 % RH
Display Numeric/graphic, backlit
Protection class IP20
Housing material Polycarbonate, PC
Terminals Disconnectable, so-called lift type for cable cross-section 2.5 mm
2
Weight OP10-230: 370 g
OP10: 215 g, including terminals
Colour Casing: Silver
Bottom part: Dark grey
Low Voltage Directive (LVD) standards: OP10-230 conforms to the requirements of the
European Low Voltage Directive (LVD) 2006/95/EC through product standard 60730-1
and EN 60730-2-9.
EMC emissions & immunity standards: This product conforms to the requirements of the EMC
Directive 2004/108/EC through standards EN 61000-6-1 and EN 61000-6-3.
RoHS: This product conforms to the Directive 2011/65/EU of the European Parliament and
of the Council.
Inputs
Analog inputs Three
AI1 PT1000 sensor, working range 0…+84°C, accuracy ± 0.5°C
AI2 PT1000 sensor, working range -30…+54°C, accuracy ± 0.5°C
SPI PT1000 setpoint device, working range 0...40°C, accuracy ± 0,5°C
Universal input One analogue or digital input
AI PT1000 sensor, working range 0…84°C, accuracy ± 0.5°C
or DI Potential-free closing contact
AGND Reference for AI and for UI when used as analog input
UI+ Reference for UI
Digital inputs Closing potential-free contact
DI+ Reference for DI
Outputs Two analogue and three digital outputs
AO 0…10 V DC; 8 bit D/A short-circuit protected
DO1 and DO2 Triac controlled, 24 V AC, 0.5 A continuous
DO3 Change-over (SPDT) relay, 230 V AC, 5 A
