Reid ROVER - Parameter Table

Electric scooters are fully charged, load is 100kg, ambient temperature is
25°C without wind, maximum speed is 25kph. However, the actual
cruising range varies with driving habit, roads, ambient temperature,
wind speed and other factors.
Parameter Table
Data and parameters vary by mode. Subject to change without notice.
Note:
Height: The height of the body to the ground.
Endurance:
27 28
MAINTAIN ME
Parameters
Description
Specifications
Battery pack
Battery manufactuerer
Guangxi Zhongke Puhui Energy Co., LTD
Battery model name
PH36-7.8
Rated voltage (VDC)
36
Maximum charge voltage
42
Rated capacity
7.8Ah
Protection
Temperature, short circuit, undervoltage,
overcurrent, overcharge, overdischarge
Motor
Rated Power [W]
290
Max Power [W]
500
Charger
Charge manufacturer
Shenzhen Fuyuandian Power Co., LTD
Charge model name
FY0634201500
Rated power [W]
63
Rated voltage input (VAC)
100-240
Rated voltage output (VDC)
42
Rated current output (A)
1.5
Charging time (H)
6-6.5
Parameters
Description
Specifications
Product
dimensions
LxWxH(MM)
1120*510*1210
Folding Size LxWxH(MM)
1120*510*530
Weight
Total scooter (KG)
15
Ride limits
Rider weight maximum (KG)
100
Rider weight minimum (KG)
30
Rider age
12-50
Main parameter
Rider height (CM)
120-200
Max speed (KM/H)
25
Charger
Max mileage (KM)
30-35
Max slope
10-15%
Road
Shall not exceed step above 1cm, and shall
not exceed gap over 3cm
Working temperature
-10-40°C
Charging temperature
0-40°C
Stock temperature
-20-45°C
Waterproof level
IPX4
