Charging Lights
33 34
Charger Indicator Light
Battery Indicator Lights
Some batteries are fitted with an external charge state indicator which can help you visually
determine the charge status of your battery by pressing the button located next to these
lights.
Multiple LED type - the more LED lights illuminated the greater the charge level.
Single LED type - Blue 70% to 100%, Green 30% to 70%, Reid 1% to 30%.
The battery can exist between the decribed state of charge, in which case the LED may
flicker both relevant colours.
Green (without battery connected)
Charger OK (ready to charge)
Red (with battery connected)
Green (with battery connected)
Check mains power, charger may be fault
Charging Process
Step 1: Be sure to check your battery charge socket for moisture and debris before
recharging.
TIP: If it is dirty please return your bike to your dealer so it can be cleaned without risk
of short-circuiting the system.
Step 2: Ensure you connect your charger to the battery charge socket prior to turning on the
charger at the wall socket.
TIP: Your battery can be charged while fitted to the bike.
Maintenance of your Battery:
"Fast chargers" with more amperage output are not available or recommended.
Replacement chargers can be ordered from your Reid Dealer.
NOTE: If the battery does not fully charge within 8 hours, stop charging and consult
with your Reid Dealer.
MAINTAIN ME
