4.4.1 To ENTER Auto Up/Retinal Mode.
4.4.1.1 Depress and HOLD either STOP switch.
4.4.1.2 With the STOP switch depressed, depress the
LOWER TOP switch on the right side of the chair back to
program that switch for Retinal Mode.
4.4.1.3 A one second beep will be heard to indicate that
switch has ENTERED Auto Up/ Retinal Mode. When depressed,
the RECLINE TOP switch on the right-hand side of the chair will
now cause the chair lift to rise and the chair top to recline.
4.4.1.4 To program the RECLINE TOP switch on the left-
hand side of the chair, use that switch and repeat the same
steps as described above.
CAUTION: ANY Chair movement that
CONTINUES after the switch is released may
be stopped by depressing the STOP Switch or
by depressing the same switch a second time.
PRÉCAUTION : TOUT mouvement de la
chaise qui CONTINUE après que l’interrupteur
est relâché peut être arrêté en appuyant sur
l’interrupteur STOP (ARRÊT) ou en pressant le
même interrupteur une seconde fois.
4.4.2 To EXIT Auto Up/Retinal Mode, repeat the
above sequence.
4.4.2.1 Depress and HOLD either STOP switch.
4.4.2.2 With the STOP switch depressed, depress the LOWER
TOP switch on the same side of the chair back.
4.4.2.3 A one second beep will be heard to indicate that
switch has EXITED Auto Up/Retinal Mode.
4.5. Home Feature
4.5.1 The Home Feature allows the user to program the
distance the chair lift will travel when starting from the fully
lowered position. Activating this Feature causes the chair to
move upward for a xed amount of time. The actual height
achieved by the chair will vary slightly from the programmed
height, depending on the weight of the patient.
NOTE: Depressing a switch causes the mode
of operation to TOGGLE between MOMENTARY
and MAINTAINING operation. If a mistake is made,
depress the same switch again to return that switch
to its previous mode of operation. If, at any time,
the user becomes lost or confused during the
programming procedure, the chair can be reset
to the factory settings by disconnecting and then
reconnecting main power to the chair. Once reset,
the programming procedure can be repeated.
REMARQUE : Appuyer sur un interrupteur fait
BASCULER le mode de fonctionnement entre
MOMENTANÉ et MAINTENU. Si vous avez fait
une erreur, appuyez de nouveau sur le même
interrupteur pour le ramener à son mode de
fonctionnement préalable. Si, en tout temps,
l’utilisateur devient perdu ou confus durant la
procédure de programmation, la chaise peut être
réinitialisée aux réglages d’usine en déconnectant
et en reconnectant l’alimentation principale à la
chaise. Une fois réinitialisée, la procédure de
programmation peut être répétée..
4.3. BEEP-ON-SWITCH Feature
4.3.1 The chair can be programmed to beep whenever a
switch is depressed. This gives the user additional feedback
on the operation of the chair. The factory design is to have
NO BEEP occur when a switch is depressed. To change this
setting the chair must be in Setup Mode. See Section 4.2.4.
on how to ENTER Setup Mode, once in Setup Mode.
4.3.2 Depress either AUTO switch on the chair back
to toggle the BEEP-ON-SWITCH feature between ON and
OFF.
4.3.3 A short beep (0.25 seconds) indicates NO BEEP
will occur when a switch is depressed. A long beep
(1.05 seconds) indicates a BEEP occur when a switch is
depressed.
4.3.4 When nished programming the chair, the MUST
be taken out of Setup Mode. See Section 4.2.4. on how to
EXIT Setup Mode.
4.4. Auto Up/Retinal Feature
The Auto Up/Retinal Feature is a convenient feature for
Retinal Specialists. When either recline switch is programmed
to operate in this mode, depressing that switch will cause
the chair lift to rise and the chair top to recline
IN-FX920
13
