Reliance FX920 - Model FX920 Chair Assembly

SEAT HEIGHT (MIN)
HIGH BASE 24 3/4"
(10 5/8" TRAVEL)
LOW BASE 22 1/4"
(8 1/2" TRAVEL)
36.5"
25.8"
32.5"
21.3"
24.58"
32.5"
47.25"±.25 HIGH BASE
44.75"±.25 LOW BASE
AT LOWEST POSITION
ADJUSTABLE
13.3"
5.5"
BASE
MODEL AND SERIAL
NUMBER PLATE
2
1
3
5, 6
11, 12
13
7, 8
9, 10
14
4
FIGURE 6
FX920 CHAIR ASSEMBLY
ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION
1
Chair Top Assembly* (See Figure 7 )
8
1761073 Upholstered Seat Assembly**
2
Base Assembly* (See Figure 8)
9
1764273 Apron Board Assembly**
3
#26 Headrest Assembly* (See Figure10)
10
1760973 Upholstered Apron Assembly**
4
1760488 Footstep
11
1767873 Center Board Assembly**
5
1764073 Back Board Assembly**
12
1761173 Upholstered Center Assembly**
6
1761273 Upholstered Back Assembly**
13
1761373 Upholstered Arm Assembly
**
7
1779273 Seat Board Assembly**
14
1765073 Scuff Pad**
** Please specify upholstery color when ordering.
To order complete Upholstery Set use P/N.
1782073 Upholstery Set - FX920
IN-FX920
19
