ITEM
PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION
1
2081203 Base
2
2065599 Base Cover
3
2065199 Base Housing-Low - RH
23 1127599 Union Tee
2065399 Base Housing-High - RH
4
2065299 Base Housing-Low - LH
25
1550599 Chair Control Cable-LV To LV
2065499 Base Housing-High - LH
26
1608192 Footswitch Assembly
5
Lift Assembly (See Figure 9)
27
1634299 Fuse, 6.3 A / 250V-120V
6
1707792 Solenoid Valve Assembly-120V 1634999 Fuse, 4 A / 250V-230V
1707892 Solenoid Valve Assembly-2
30V 28 1617899 AC Input Module
7
1702892 Keyshield Assembly-Low* 29 1597199 Fusedrawer, 2 Pole
1702992 Keyshield Assembly-High*
30
0458999 Tubing-5 in
8
2720092 Pump/Motor Assembly-120V
31
1597299 Capacitor, Starting-120V
2720192 Pump/Motor Assembly-230V 2002199 Capacitor, Starting-230V
9
1547899 Piston Rod Bolt 32 2031599 Capacitor, Starting-230V
For Actuator Motor-230V (See Figure
7, Item 20)
10
1525899 Set Screw-#10-24 x 1/2
11
0607299 Washer 33 1994699 Power Line Filter- 6A
12
2721092 Hose Assembly
34
2720392 Grey Base Cable Assembly
13
1506392 Pressure Tube Assembly
35 2720292
Black Base Cable Assembly
14
2025199 P.C. Board Assembly
36 1767599
6 Circuit Micro Receptacle
15
2720992 AC Input Assembly
37 1767499
4 Circuit Micro Receptacle
16
0458999 Tubing-5-1/2
38 1663899
Actuator Motor Ground Wire Assembly
17
1081999 Tubing Insert
39 1720399
PH Phil w/Lock Wa
sher-#10-24 x 1/2
18
1547999 Snap Bushing
40 2081099
Housing Mount Bracket
19
0559999 Thrust Bearing
41 0708599
HHCS 3/8-16 x 1.5
20
0560099 Thrust Washer
42 2081099
Housing Mount Bracket
21 0123885 Lock Nut
43 1569999
Circuit Board Support
22
1548195 Wiring Tube-High
1548395 Wiring Tube-Low
24
1659299
Power Cord Assembly 120V (US)
2832299 Power Cord Assembly 230V (US)
2363100 Power Cord Assembly INT’L Options
*Please specify paint color when ordering.
To Next Page
