ENGLISH

DESIGNATION

1. Theft Protection: Kensington Safety Slot

2. Volume Dial (Headphones)

3. Gain Dial

4. USBStatusDisplay

5. Status LED (Signal Output)

6. Status LED (Signal Input & Clip)

7. USB Port

8. Phono/LineSwitch

9. HeadphonesConnection(ComputerMonitoring/Soundcard)

10. AudioOutput(RCA-ComputerMonitoring/Soundcard)

11. Grounding Screw

12. Phono/LineInput(RCA)

CONNECTIONS

1. First connect the sound source from which you would like to record (i.e. turntable, tape deck) to the

Phono/LineInput-12-.Dependingonwhetherthesignalsourcehastobeampliedandequalised

(Phono)ornot(Line),adjustthecorrespondingsourceviathePhono/LineSwitch-8-.Ifyouwantto

connect a turntable please also connect the grounding cable to the Grounding Screw -11-.

2. NowconnectafreeUSBportofyourcomputer(PC/Macversion1.0/2.0compatible)totheiPhono

2‘s USB connection -7-. To do so please use the included USB cable.

3. If you want to monitor the input signal through your computer (software playthrough) you can con-

nect a stereo system via RCA for example to the Line Output -10-. Here you can solely monitor the

output signal of your computer. You can also use iPhono 2 as normal computer soundcard for play-

back.

4. HeadphonesConnection

In order to control a recording, you can connect your headphones to the corresponding connection

-9-. Here you can solely monitor the output signal of your computer. (playback & software playth-

rough)

OPERATION

1. Input Select

 WiththePhono/LineSwitch-8-youcanselect“Phono”foraturntableinputsignal.Forothersour-

cesputtheswitchinthe“Line”position.

2. Input Volume Dial

 WiththeGainDial-3-youcanleveltheinputsignal.PleasealsoconsidertheSignal/ClipLED-6-.

3. Signal/ClipLED

 Tochecktheinputsignal,besidestheGainDial-3-,youcanalsousetheSignal/ClipLED-6-.Ifthe

signal is overmodulated the LED -6- will be illuminated orange. This way you can easily level the

signal optically via the Gain Dial -3-.

4. HeadphonesVolume

With the volume Dial -2- it is possible to adjust the headphones volume. (playback & software play-

through from computer)
