REMKO GPM
PARAM
K
TSP
Factory
setting
Standard Description
1 A1 0 0 - 100 Minimum modulation value
2 A2 0 0 - 100 Maximum modulation value
3 A3 70 20 - 100 Starting output
4 A4 20 0 - 255 Value of the integral factor
5 A5 10 1 - 100 Value of the proportional factor
6 A11 25 25 - 255 Stabilisation time of the flame
7 A17 4 0 - 4 Number of automatic resets after fault F1
8 A28 50 0 - 100 Percentage of OUT3 activation
9 A34 10 10 - 95 REG SAN minimum value
10 A35 0 0 - 1 Summer operation of the fan
11 C1 0 0 - 1 Room correction
12 C3 60 0 - 255 Delay time of the fan ON
13 C4 120 0 - 255 Delay time of the fan OFF
14 C5 0 0 - 1 Heating mode release
15 C8 0 0 - 1 Frost protection release
16 ST3 7.5 -5 + 30 Frost protection switchpoint temperature
17 A12 0 0 - 1 Release of external room sensor
18 A16 90 1 - 99 Correction coefficient
19 A24 1.5 1 - 20 Correction neutral range
20 A15 0 0 - 1 Selection of the PWM speed combination table
21 A31 2 2 - 3 Divisor for HALL message
REG SAN
ST1 21 10 - 95 Sensor NTC1 switchpoint
Control PCB parameter table
