45
Spare parts list
No. Designation GPM15 GPM25 GPM35 GPM55 GPM 75
1 Control PCB 1110440 1110441 1110442 1110443 1110444
2 F1 Fuse 4A 1110445 1110445 1110445 1110445 1110445
3 F2 Fuse 2.5A 1110446 1110446 1110446 1110446 1110446
4 Terminal block M1 1110447 1110447 1110447 1110447 1110447
5 Connection for potential equalisation 1110448 1110448 1110448 1110448 1110448
6 Transformer 1110449 1110449 1110449 1110449 1110449
7 RED control lamp 1110521 1110521 1110521 1110521 1110521
8 GREEN control lamp 1110522 1110522 1110522 1110522 1110522
9 Safety temperature limiter 1110452 1110452 1110452 1110452 1110452
10 Blind plug 1110453 1110453 1110453 1110453 1110453
11 Summer/Winter toggle 1110454 1110454 1110454 1110454 1110454
12 Electrical connection bush 1110455 1110455 1110455 1110455 1110455
13 Unlock key 1110456 1110456 1110456 1110456 1110456
14 Cable connections 1110457 1110457 1110457 1110457 1110457
15 Ignition gas pipe 1110458 1110458 1110458 1110458 1110459
16 Flame monitoring unit 1110460 1110460 1110460 1110460 1110460
17 Ignition burner solenoid valve 1110461 1110461 1110461 1110461 1110461
18 Gas valve 1110462 1110462 1110462 1110462 1110463
19 Venturi tube 1110464 1110465 1110465 1110466 1110466
20 Burner fan 1110467 1110467 1110467 1110468 1110469
21 Ignition cable 1110470 1110470 1110470 1110470 1110471
22 Ionisation cable 1110472 1110472 1110472 1110472 1110472
23 Inspection glass with seal 1110473 1110473 1110473 1110473 1110473
24 Ignition gas burner 1110474 1110475 1110476 1110477 1110478
25 Ignition electrode 1110479 1110479 1110479 1110479 1110479
26 Ionisation electrode 1110480 1110480 1110480 1110480 1110480
27 Burner flange seal 1110481 1110481 1110481 1110481 1110481
28 Burner fan seal 1110482 1110482 1110482 1110482 1110483
29 Burner pipe seal 1110484 1110484 1110484 1110484 1110485
30 Natural gas ignition nozzle 1110486 1110487 1110488 1110489 1110490
30a Liquid gas ignition nozzle 1110491 1110492 1110493 1110494 1110495
31 Gas valve seal 1110496 1110496 1110496 1110496 1110496
32 Gas supply pipe 1110497 1110497 1110497 1110497 1110498
33 Gas supply pipe seal 1110499 1110499 1110499 1110499 1110500
34 Counter nut 1110501 1110501 1110501 1110501 1110502
35 Air outlet grid 1110503 1110504 1110504 1110505 1110506
36 Silicon seal 1110450 1110450 1110450 1110450 1110450
37 Flue gas connection 1110508 1110508 1110508 1110508 1110509
38 Closure 1110510 1110510 1110510 1110510 1110510
39 Air supply connection 1110511 1110511 1110511 1110511 1110512
40 Door hinge 1110513 1110513 1110513 1110513 1110513
41 Temperature sensor 1110514 1110514 1110514 1110514 1110514
42 Fan 1110515 1110516 1110517 1110518 1110519
o Fig.
Electrical connection plug 1110520 1110520 1110520 1110520 1110520
When ordering spare parts, please state the computerised part no., unit number and type (see identification plate)!
