REMKO RVT 262 - Sound Pressure Level

2.3 Sound pressure level
1m1m
5m
10m
1m
5m
10m
Fig. 3: Distance-dependent sound pressure level for the outdoor unit in relation to installation type, in accord-
ance with the drawing
Distance-dependent sound pressure level *)
Unit type
Sound power max.
[dB(A)]
Installation type, in
accordance with the
drawing
1m
[dB(A)]
5m
[dB(A)]
10m
[dB(A)]
15m
[dB(A)]
RVT 262 59
In free field 51,0 37,0 31,0 27,5
In front of a wall 54,0 40,0 34,0 30,5
RVT 352 63
In free field 55,0 41,0 35,0 31,5
In front of a wall 58,0 44,0 38,0 34,5
RVT 522 61
In free field 53,0 39,0 33,0 29,5
In front of a wall 56,0 42,0 36,0 32,5
RVT 682 67
In free field 59,0 45,0 39,0 35,5
In front of a wall 62,0 48,0 42,0 38,5
*) All information without guarantee. Exact sound values must be determined by an expert!
