ZXT-800 AC/AV MASTER USER MANUAL
3.3 Step-3 Setup Automatic Status Report Associate to Gateway
Please refer to your primary controller (gateway) instruction for more detail. Normally, User
can ignore this step during the setup.
ZXT-800 support 1 association group, Association Group #1 (max. 1 node) is default to
associate with the primary controller (Gateway/Hub/Controller) for ZXT-800 status change
report, refer to below for report details:
• Current Room Temperature (report in precision of 0.5 °C or 1°F), It will be according to
Conguration Parameter 30 setting to decide the trigger level.
• Current Battery Level (Only apply in Low Battery Warning happened)
• Device Reset Locally Notication (Only report when the ZXT-800 has been triggered
the RESET TO DEFAULT)
3.4 Step-4 Setup IR code
The user interface of setup the IR code varies from different gateways. If gateways have
dedicated UI for the IR code setup, please refer to the gateway UI and ignore the below
steps.
If your gateway does not have dedicated UI for ZXT-800 IR code setup, but support Z-Wave
Conguration Command Class. Please refer to below method-A to setup the IR code using
the conguration options in your gateway.
 Continued on next page
