Rena envelope imager III - Page 63

User’s Manual - Revision C Section A - 2
Appendix A • RENA Systems Envelope Imager III MAIN MENU Flow Chart
----MAIN MENU----
5.Address Recovery
ADDRESS RECOVERY
A. Get Address
02: John P. Jones
Hit Recover ENTER to
NONE TO RECOVER.
ADDRESS RECOVERY
B. Clear Memory
Clear the +YES
Address Buffer? -NO
----MAIN MENU----
6. Clear Counter
Clear address +YES
(pcs) counter? -NO
Address counter
cleared. Pieces=0
----MAIN MENU----
7. Job Settings
JOB SETTINGS
A. Load
Load Settings +MORE Printer is set for
from Job #3? -LESS Job #3.
JOB SETTINGS
B. Save
Save Settings +MORE Job #6 has been
as Job #6? -LESS saved.
----MAIN MENU----
8. Conveyer time
CONVEYER TIME + MORE
*0.00 Seconds - LESS
----MAIN MENU----
9. Image Overlay
IMAGE OVERLAY
A.First Image Overlay
Enable
FIRST IMAGE OVERLAY FIRST IMAGE OVERLAY
Exit
IMAGE OVERLAY
B.Clear Overlay
CLEAR OVERLAY
Clear
CLEAR OVERLAY
Exit
IMAGE OVERLAY
C.Print Overlay First
*Enable
PRINT OVERLAY FIRST PRINT OVERLAY FIRST
Disable
----MAIN MENU----
10. Purge Print Head
Purge print + YES
Head? - NO
----MAIN MENU----
11. Ink Count
Enter for 100% +NEXT
Hd01=100% Full -PREV
Enter for 100% +NEXT
Hd02=100% Full -PREV
Enter for 100% +NEXT
Hd03=100% Full -PREV
Enter for 100% +NEXT
Hd04=100% Full -PREV
Enter for 100% +NEXT
Hd05=100% Full -PREV
Enter for 100% +NEXT
Hd06=100% Full -PREV
