1.08
REAR HEAD RESTRAINT
Side head restraint
To raise it:
Simply slide it upwards (only one
position possible).
To remove it:
Press tabs 1 on the head r estraint
guides.
To replace it:
Insert the rods into the sleeves, with
the notches to the front, and lower
the head restraint.
Centre head restraint
To raise it:
Simply slide it upwards (only one
position possible).
To remove it:
Press tabs 1 on the h ead restraint
guides.
To replace it:
Insert the rods into the sleeves, with
the notches to the front, press tabs 1
and lower the head restraint.
The head restraint is
important for safety. Ensure
that it is in place and in the
correct position. The
distance between your head and
the head restraint should be as
small as possible. The top of your
head should be in line with the top
of the head restraint.
