3.03
HEATING - VENTILATION (continued)
Design and features
Air from the outside enters the
passenger compartment via the
vents located above the lenses and
through the grilles which must not
be allowed to become blocked
(snow, dead leaves, etc.).
The outside air is filtered by two
filters which need to be kept clean
and in good condition if they are to
remain efficient before it is blown
into the passenger compartment.
Provisionismadetochangetheseas
part of your vehicle's servicing
schedule.
The air thus filtered and cleaned
(pollen and particles, etc. removed)
actively contributes to the comfort
and well-being of the vehicle's
occupants since it limits the dust
deposits in the passenger
compartment.
The heating system consists of two
radiators located on either side of
the dashboard. The driver can
control the temperature of the
passenger and driver radiators. The
front passenger can only control the
one on his or her side.
Air vents (air outlets)
1 Air diffusers for rear seats
2 Air diffusers for front footwells
3 Windscreen de-icing - demisting
outlets
4 Driver's control unit
5 Deflector de-icing - demisting
outlets
6 Adjustable side vents
7 Windscreen de-icing - demisting
outlets
8 Adjustable centre air vents for
unheated air
9 Passenger's control unit
Instrument panel air vents
In order to provide individual
ventilation, side vents 6 and centre
vents 8 are controlled manually:
adjustment of the volume of air flow
and direction of flow.
Once you have selected the
distribution of the air supply, you
should adjust the flow.
- The centre air vents 8 supply the
air at ambient temperature
(outside or recirculated air) or at a
cooler temperature if the air
conditioning is in operation.
