5.10
FRONT LIGHTS: changing the bulbs
Changing a dipped headlight
discharge bulb
They are marked by a label 1 on the
lens unit.
The headlight bulb must be
changed by a Renault Dealer.
Changing a main beam
headlight bulb
Remove the plastic cover by turning
it through 90°.
- Remove the bulb connector.
- Unclip spring 2 and take out the
bulb.
Type of halogen bulb: H7.
Do not touch the glass of the
halogen bulb. Hold it by its base.
Front side lights
- Take out the bulb holder 3 by
turning it through 90° to reach the
bulb.
- Replace the bulb.
Bulb type: W 5 W.
Take care when working
under the bonnet as the
engine cooling fan may
start up at any moment.
