1.10
FRONT SEATS (continued)
Access to the rear seats
Pull lever 1 towards you and tip the
seat forwards.
The seat has a memory which
allows it to relock the seat in its
initial position when it is pushed
back as far as its stored stop.
Ensure that the runners
and seatback are locked
in place correctly.
From the rear, pull the lever 3 to tip
the seat forwards.
Heated seats
(Initiale version)
With the ignition on, press switch 2;
the corresponding indicator light on
the instrument panel will light up.
Even if the indicator light
is lit up, the system is not
necessarily activated.
The system has a
thermostat and only operates
when the passenger compartment
temperature is less than 12°C
(with a tolerance of + or –4°C).
