1.30
CHILD SAFETY (continued)
Installation principle
Front-facing Isofix seat
When a front-facing child seat is
installed, the front seat must not be
moved back beyond the halfway
point on the seat runners and the
seatback must be in an upright
position.
Rear-facing Isofix seat
When a rear -facing child seat is
installed, the front seat must not be
moved forward beyond the halfway
point on the seat runners.
The seat back must be close to or
touching the shell of the child seat.
Fitting a child seat
- Before fitting and using the seat,
read the instructions provided
carefully;
- Insert the belt guides 1 (delivered
with the seat) into the slots
provided between the seatback
and the seat;
- Offer up the seat catches 3
opposite the two rings 2 fitted in
the rear side seats.
