5.19
FUSES (continued)
Allocation of fuses
(the presence of fuses depends on the vehicle equipment level)
Symbol Allocation
Rear door locking /
Child safety
Electric windows
Passenger compartment
ventilation
General supply
Central door locking
Engine immobiliser
Rear screen wiper.
Interior lighting / Wiper
with automatic function /
Automatic lights
Brake lights
Radio
Symbol Allocation
Climate control
Manual air conditioning
Front cigarette lighter
ABS / E.P.S.
Driver's electric window
control
Electric driver's window
Brake lights/luggage
compartment light
Horn
Electric door mirrors
Automatic dashboard
heating and ventilation
Indicator lights
Some accessories are protected by
fuses located in the engine
compartment.
However, because they can be
difficult to access, you are advised
to have your fuses replaced by a
RENAULT Dealer.
