A
B
C
NU750_2_G3-FRA.qxd 25/07/05 9:48 Page 3.04
3.04
HEATING/VENTILATION
Controls
A Air distribution.
B Air temperature adjustment.
C Adjustment of the amount of air
blown into the passenger
compartment.
Distribution of air in the
passenger compartment
Move control A.
Position
m
All the air flow is directed to the
dashboard vents.
This selection is not appropriate if
all the air vents are closed.
Position
h
The air flow is distributed between
the dashboard vents and the front
and rear foot wells.
Position
i
The air flow is distributed between
all the vents, the front side window
demisting vents, the windscreen
demisting vents and the front and
rear foot wells.
Position
d
For more effective demisting, close
the central dashboard vents and
direct the side air vents towards the
side windows.
All the air is then directed to the
windscreen and front side window
demisting vents.
NU750_2_G3-ENG.qxp 9/7/2005 5:18 PM Page 3.04 (Black plate)
