LUGGAGE NET
Luggage net 1
(depending on equipment level) can
be placed behind the front seats or
behind the rear bench seat.
Note: when the net is placed behind
the rear bench seat, the unused front
collapsible supports 6 should be
kept in the upper position so that
passengers do not strike their heads
when getting into or out of the
vehicle or when the vehicle is being
driven.
Positioning the net
- upper section: attach rings 7 to
front or rear collapsible supports 6
fixed in the lower position.
- lower section (behind the rear
bench seat): fasten straps 2 through
lashing rings 5 on the floor.
Pull on loops 3 to tighten the straps
and then pull up and lock
adjustable runners 4 into position
so that they are completely secure.
Fitting the net (continued)
- lower section (behind the front
seats, rear bench seat raised up):
fasten straps 2 through holes 8
located on the rear bench seat
hinges.
Tighten the straps as shown
previously.
