5.12
REAR LIGHTS: replacing bulbs
The bulbs are under
pressure and can break
when replaced.
Risk of injury.
Rear lights
Remove nuts 1 and release the rear
light from its housing.
Unclip the bulb holder by pressing
tab 2.
3 Tail light and brake light
Pear-shaped bulb, bayonet type
with 2 filaments P 21/5 W.
4 Indicator
Pear-shaped bulb, bayonet type P
21 W.
5 Reversing light (right-hand side)
Fog light (left-hand side)
Pear-shaped bulb, bayonet type P
21 W.
