Renesas E2 Lite User Manual

E2 Lite Outline
R20UT3240EJ0300 Rev.3.00 Page 13 of 36
May.15.20
1.4 Specifications
Table 1.2 lists the specifications of the E2 Lite.
Table 1.2 Specifications of the E2 Lite
Item
Description
Emulator type
E2 emulator Lite
Type name: RTE0T0002LKCE00000R
PC interface USB 2.0 (full speed)
Target interface
14-pin (2.54-mm pitch) connector
20-pin (1.27-mm pitch) connector
10-pin (1.27-mm pitch) connector
Power voltage for the emulator USB-bus power supply (VBUS 4.5 V min. / 500 mA max.)
Power supply for the target MCU
Supplied from the user system or the emulator (3.3 V: 200 mA max.*)
Supported voltages for the user
system
Within 1.8 V to 5.5 V, and in the range of the MCU’s power supply voltage while
in operation.
For more information, see the additional document for user’s manual for the
E1/E20 emulator or E2 emulator Lite.
External dimension (main body)
96.2 mm × 52.7 mm × 17.2 mm
Weight 47 g
Operating temperature
5 to 35°C (no condensation)
Storage temperature -10 to 60°C (no condensation)
EMC
EU: EN 55032 Class A, EN 55024
USA: FCC part 15 Class A
Note: When 500 mA is supplied from USB VBUS

Renesas E2 Lite Specifications

General

On-Chip Debugging	Yes
Programming	Yes
Interface	USB
Operating System Support	Windows
Manufacturer	Renesas
Target Devices	Renesas MCUs
Supported Interfaces	JTAG
Debugging Features	Breakpoints
Software Compatibility	Renesas E2 Studio
