7. Design and Manufacturing Information
The design and manufacturing information about EK-RA4M1 v1 board are available in the “EK-RA4M1v1
Design Package” available on renesas.com/ra/ek-ra4m1
.
• Design package file name: ek-ra4m1-v1-designpackage.zip
• Design package contents
File Type
Content
File/Folder Name
File (PDF)
Schematics
ek-ra4m2-v1-schematics
File (PDF)
Mechanical Drawing
ek-ra4m2-v1-mechdwg
File (PDF)
3D Drawing
ek-ra4m2-v1-3d
File (PDF)
BOM
ek-ra4m2-v1-bom
Folder
Manufacturing Files
Manufacturing Files
Folder
Design Files
Design Files - Altium
8. Website and Support
Visit the following URLs to learn about the kit and the RA family of microcontrollers, download tools and
documentation, and get support.
EK-RA4M1 Resources renesas.com/ra/ek-ra4m1
RA Product Information renesas.com/ra
RA Product Support Forum renesas.com/ra/forum
Renesas Support renesas.com/support
