Technical Data
2934 2000 2934 2500 2934 3000 2934 3500
Nominal voltage 230 V 220 V 120 V 100 V
Permissible mains voltage (+ / - 10 %) 230 - 240 V 220 V 120 V 100 V
Mains frequency 50 / 60 Hz 50 / 60 Hz 50 / 60 Hz 50 / 60 Hz
Power consumtion *) 490 W 460 W 480 W 480 W
CAM interface RJ 45 socket
LpA **) (at max. volume ow) 55 dB(A)
Input signal
- Low
- High
0 - 5 V
15 - 24 V
Output signal
- max. pull-up voltage
- max. switching current (I)
- internal resistor
24 V
5 mA
150 Ohm
Filterquality Class M according to EN 60335-2-69
Weight (empty) approx 13.2 kg
[approx 29.1 lbs]
Dimensions (width x height x depth) 245 x 440 x 500 mm
[9.6 x 17.3 x 19.7 inch]
*) at nominal voltage
**) Sound pressure levels according to EN ISO 11202
