AUX 1 and AUX 2 sockets
Use the provided jack cable with 3.5 mm jack plug to connect the headphones output of your TV or any
other audio source (e.g. smartphone) to the AUX 1 (14) or AUX 2 (15) sockets.
MP3 PLAYER
SMARTPHONE
TV
AUX 1 AUX 2
Use the provided RCA cable with 3.5 jack plug to connect a suitable audio source to the AUX 1 or AUX 2
sockets.
TV
AUX 1 AUX 2
AC ~ port for mains cable
Before plugging in the device, verify that the information on the product's rating plate
correspond with your household power supply.
Make sure to carry out all connections before
connecting the mains cable. Connect the mains cable
to the AC ~ port (11) and a suitable wall socket.
