9
3. Unscrew butterfly nut tilt to desired angle and lock butterfly nut
To maximize the output, adjust the angle of the suitcase regularly to track the sun’s movement
throughout the season
Summer
πœƒ = πΏπ‘Žπ‘‘π‘–π‘‘π‘’π‘‘π‘’ – 15Β°
Fall and Spring
πœƒ = π‘Žπ‘‘ π‘™π‘Žπ‘‘π‘–π‘‘π‘’π‘‘π‘’
Winter
πœƒ = πΏπ‘Žπ‘‘π‘–π‘‘π‘’π‘‘π‘’ + 15Β°
πœƒ
