Technical Specifications
Charge Controller Electrical Parameters
Model
VS1024BN
VS2024BN
VS3024BN
Nominal system voltage
12V/24V auto recognition
Rated battery current
10A
20A
30A
Rated load current
10A
20A
30A
Max. battery voltage
32V
Max. Solar Input
48V
Equalize charging voltage
Sealed: 14.6V, Flooded: 14.8V, User-defined: 9~17V
Boost charging voltage
Gel: 14.2V, Sealed: 14.4V, Flooded: 14.6V, User-defined: 9~17V
Float charging voltage
Gel /Sealed /Flooded: 13.8V, User-defined: 9~17V
Low voltage reconnect
voltage
Gel /Sealed /Flooded: 12.6V, User-defined: 9~17V
Low voltage disconnect
voltage
Gel /Sealed /Flooded: 11.1V, User-defined: 9~17V
Self-consumption
≤15mA(12V); ≤10mA(24V);
Grounding
Common negative
Temp. compensation
-3mV/℃/2V
Relative humidity
10%~90% Non-condensation
Communication
RS485 / RJ45 interface
LCD temperature
-20℃ ~ +70℃
Working temperature
-25℃ ~ +55℃
Humidity
≤95% N.C.
Enclosure
IP30
Overall dimension
6.38x3.35x1.57inch
(162x85x40mm)
6.38x3.94x1.97inch
(162x100x50mm)
7.87x4.05x2.28inch
(200x103x58mm)
Terminals
4mm
2
(Up to #12 AWG)
10mm
2
(Up to #8 AWG)
16mm
2
(Up to #6 AWG)
Net weight
0.66 lbs. (0.3kg)
0.88 lbs. (0.4kg)
1.54 lbs. (0.7kg)
Battery Type
Gel, Sealed (AGM), and Flooded
