Renogy 100W - Device and Parameter Settings

12
2. Device Set
Use to cycle through the screens. Press to select
Modify the date and time for the charge controller.
Time is displayed in military time (24Hr) and will be
reflected in the default screen. Select Save when
finished. The user will have to select save
parameters after every screen.
Modify the time the backlight is on for the charge
controller. Backlit operation is in effect once the last
button is pressed. The user could use the ID to
connect to a tracer meter and save parameters.
Select Save Parameters when finished.
Choose between Celsius or Fahrenheit when viewing
system status temperature.
3. Parameter Set
NOTE: To customize charge parameters, TYPE must be set to USER under 5. Rated Value.
Otherwise this screen is only for information in regards to the charge parameters.
NOTE: Minimum and maximum charge parameter values can be found in Technical
Specifications
Indicates Temperature Compensation. Temperature
fluctuation can affect performance in the system.
Therefore, the purpose of temperature compensation
is to adjust the performance of the system to keep
the system functioning normally.
Parameters for Over-Voltage Disconnect, Charging
Limit, and Over-Voltage Reconnection.
Device Set
Temp Unit:
>Cel Fah
Device Set
ID: 001
Backlit: 000 sec
Save Parameters?
>Save Cancel
Device Set
Date: 00-00-0000
Time: 00:00:00
Parameter Set
Over Vol. Disc: 16.0V
Charg Lmt: 15.0V
Over Volt. Rect: 15.0V
Parameter Set
Temp Compensate Coeff
-03.0 mV / C ° / 2V
ENTER/ 
 / -
 / 
