Renogy 2000W User Manual

20
Technical Specifications
Model
RNG-500W
RNG-1000W
RNG-2000W
Rated Power
500 W
1000 W
2000 W
Surge Power
1000 W
2000 W
4000 W
Rated Voltage
12 VDC
Rated Voltage
Range
11 V – 15V
Input Voltage
DC ≥ 10V ± 0.5V
Over-Voltage
Range
16V ± 0.5V
Output Voltage
AC 110V ± 10%
Output Frequency
60 Hz
Self-Consumption
.52 A
1.2 A
1.7 A
Waveform
Pure Sine Wave
USB outlet
5V, 2A
Operation
Temperature
-10°C  (+)50°C / 14°F  122°F
Dimensions
8.87 x 4.75 x 2.75 in
225 x 120 x 69 mm
11 x 5.5 x 2.87 in
279 x 139 x 72 mm
17.62 x 7.87 x 3.25 in
447 x 199 x 82 mm
Weight
3.50 lbs
1.58 kgs
5.65 lbs
2.56 kgs
12.85 lbs
5.82 kgs
AC Sockets
1
2
4

Renogy 2000W Specifications

General

Continuous Power	2000W
Surge Power	4000W
Input Voltage	12V DC
Output Voltage	120V AC
Output Waveform	Pure Sine Wave
Output Frequency	60Hz
THD	<3%
Operating Temperature Range	-4°F to 104°F (-20°C to 40°C)
Protection	Overload, Over Temperature, Short Circuit
Efficiency	90%
USB Port	5V/2.1A
Under Voltage Protection	10V DC
