Renogy Battery Monitor User Manual

08
Troubleshooting
When the battery current is low the Renogy Battery Monitor will enter a low power (sleep
mode) and the backlight will turn off, press any button and the backlight will turn on for
10s.
When connecting the load, if the backlight is blinking, the B- and P- of the shunt are wired
inversely.
When the current changes frequently the data acquisition may produce an error, and it
may affect the accuracy.
When charging or discharging. The Renogy Battery Monitor will be working and the
capacity displayed will be real-time numbers.
Technical Specifications
Description Parameter
Working Voltage
Working dissipation
Standby dissipation
Voltage accuracy
Current accuracy
Capacity accuracy
Backlight on current(>50A)
Preset capacity value
Temperature range
Weight (LCD Interface)
Size (LCD Interface)
Shielded Wire
B+ Wire
10.0 - 120.0 V
10.0 - 15.0 mA
1.0 - 2.0 mA
±1.0 %
±1.0 %
±1.0 %
100 mA
0.1 - 9999.0 Ah
-10-60°C（14-140°F）
2.6 oz / 75 g
3.9*2.4*0.7 inch (9.9*6.1*1.8 cm)
20ft (6m)
3ft (1m)
