Renogy MPPT Series User Manual

!
24
Threshold Voltage
Description
Parameter
NTTV (Night Time Threshold Voltage)
5V; x2/24V
DTTV (Day Time Threshold Voltage)
6V; x2/24V
Table 7-3 Threshold Voltages
Temperature Compensation
Description
Parameter
Temperature Compensation Coefficient
(TEMPCO)*
-30mV/°C/12V (25°C ref)
Table 7-4 Temperature Compensation
*Compensation of equalize, boost, float and low voltage disconnect voltage
Environmental Parameters
Environmental
Parameter
Ambient Temperature Range
-35 °C to +55 °C
Storage Temperature Range
-35 °C to +80 °C
Humidity Range
10% to 90% (NC)
Enclosure
IP30
Altitude
≤ 3000m
Table 7-5 Environmental Parameters
Mechanical Parameters
Mechanical
Parameter
Dimension
240 x 169 x 91 mm (9.45 x 6.65 x 3.58 in)
Mounting Holes
180 x 160 mm (7.09 x 6.30 in)
Mounting Hole Size
Φ 5 mm
Terminal
25 mm
2
Weight
2.05 Kg (4.52 lbs.)
Table 7-6 Mechanical Parameters

Renogy MPPT Series Specifications

General

Max Battery Voltage	32V
Type	MPPT
Rated Charge Current	20A, 30A, 40A, 60A
Nominal System Voltage	12V/24V auto detect
Max PV Input Voltage	100VDC
Communication	RS232, Bluetooth
Maximum PV Input Power	260W/12V; 520W/24V (20A), 390W/12V; 780W/24V (30A), 520W/12V; 1040W/24V (40A), 780W/12V; 1560W/24V (60A)
Max Solar Input Current	20A, 30A, 40A, 60A
