REO REOVIB MFS 268 User Manual

REOVIB MFS 268
Operating Instructions EtherNet/IP - Programming
14
7.3 RESET Controller
Open
Write e
n
able
Word Code
send
Code
received
1 0000 H
0000 H
2 C0DE H Write Enable Address C0DE H Acknowledge
3 B5C9 H Write Enable Value B5C9 H Acknowledge
4 8000 H +
Control bits
Set mode bit = 1 C0DE H Acknowledge
Write Parameter
1 0000 H
0000 H
2
9400 H
Parameter address
Reset
+ R / W - Bit
0000 H
Acknowledge
3
C009 H
RESET.
0000 H
4 8000 H +
Control bits
Set mode bit = 1 C0DE H
Allow approximately 0.5 sec. for RESET
